AM42-0007 2 Watt 14.0 - 14.5 GHz RF Amplifier
- Brand: M/A-Com
- Product Code: AM42-0007
- Availability: In Stock
-
USD $63.00
AM42-0007 2 Watt 14.0 - 14.5 GHz RF Amplifier
| Amplifiers | |
| Output IP3 | + 41 dBm |
| Frequency | |
| Frequency Min | 14000 MHz |
| Frequency Max | 14500 MHz |
| Gain Value | |
| Gain | 22 dB |
| Operating Voltage | |
| Voltage DC | 9 VDC |
| Semiconductor Device Parameters | |
| Amplifier Type | Medium Power ( 1-5 Watts ) |
| Impedance Ω | 50 |
| Mounting Type | Bolt Down |
| Noise Figure | N/A |
| Operating Current | 1100 mA |
| Output P1dB | 33 dBm |
| Package / Case | CR-15 |
