3 dB 600 - 3800 MHz LOW PIM RF Hybrid Coupler N Type Connectors
- Brand: RF Components
- Product Code: RFHC600-3800-NF
- Availability: In Stock
-
USD $87.25
3 dB 600 - 3800 MHz LOW PIM RF Hybrid Coupler N Type Connectors
DATA SHEET
| Connectors | |
| Connector 1 | N Female |
| Coupling Factor | |
| Coupling | 3 dB |
| Frequency | |
| Frequency Min | 600 MHz |
| Frequency Max | 3800 MHz |
| Impedance | |
| Impedance Ω | 50 |
| Insertion Loss | |
| Insertion Loss dB | .8 dB |
| PIM Rating | |
| PIM Rated | Yes |
| RF Power Levels | |
| RF Pwr Max | 300 Watts |
